45072-01 • 10/21/10 • Hunter Fan Company

3 • Assembling and Hanging the Fan

3.5

3.7

3.4

3.6

Raise the fan and place the hook on the hanger bracket (2) through the

round hole in the rim of the canopy (3).

Remove the screws from the hanger bracket (2).

Place the low prole washer (27) from the parts sack into the canopy. Place the canopy trim ring (4) and canopy (3) with washer (27) on top of

the fan assembly. Align the screw holes in the washer with the holes in the

adapter. Assemble securely with three locking screws (100).

WARNING:

Do not carry

or lift fan by

canopy.

Fan

may fall if not

assembled as

directed in these

installation

instructions.

Low Proﬁle Instructions: Low Proﬁle Instructions:

Low Proﬁle Instructions:

100
